TR’s Coiled tubing units are comprised of several components, which provides a complete system for performing coiled tubing workover.
As a packaged Coiled Tubing System, it could be operated in both land based and offshore working conditions with best performance.
Widely used in washing, sand plug flushing, paraffin removing, acidizing, nitrogen
injection gas lifting, fishing, milling, and electric logging etc.
Customized design & solution for your special and/or specific requirements or working environments. World leading brand parts, and minimum maintenance.
|
Model |
TR-160(50K) |
TR-290(65K) |
TR-380(85K) |
|
Max. rated lifting force kN(lbs) |
227(50000) |
290(65000) |
380(85000) |
|
Max. snubbing force kN(lbs) |
113.5(25000) |
140(32500) |
190(42500) |
|
Max. speed(high speed) m/min(ft/min) |
60(197) |
60(197) |
60(197) |
|
Max. Speed(low speed) m/min(ft/min) |
30(98) |
30(98) |
30(98) |
|
Tubing reel Capacity m |
4500-1.5 in 3000-1.75 in |
6100-1.5 in 4200-1.75 in |
7500-1.5 in 6300-1.75 in |
|
Rated working pressure MPa(psi) |
70(10000) |
70(10000) |
70(10000) |
|
Power pack |
CAT engine + Pump |
CAT engine + Pump |
CAT engine + Pump |
|
Data Acquisition System |
Equiped |
Equiped |
Equiped |
|
Injector |
50K |
65K |
85K |
|
BOP |
2-9/16” ram |
3-1/16” ram |
3-1/16” or 4-1/16” ram |
|
Crane |
Hydraulic Crane 12T |
Hydraulic Crane 16T |
Hydraulic Crane 18T |
|
Optional is available for cold temperature package and other manufactures/models |
|||
